Creating an IPS Structure using Tetgen
For in plane switching structures there is an interface at the
top and bottom of the structure between the LC and air or glass.
Although in the following example this material is neglected, for
accurate modelling it is crucial that these layers are included.
If the LC boundary is left free, this is equivalent to an interface
between LC and a material with dielectric constant of zero! Work
is currently underway change this default behaviour to an air-LC
interface.

This program visualises results on both irregular and regular 2D
and 3D meshes. Director plots can be made across slices, or sampled
regularly in 3D space. Iso-surface plots of potential, twist and
tilt can be made. Built in Extended optics code, for image plots
or viewing angle plots. Free energy calculation, surface and contour
plots. Provides a means to rapidly convert results from irregular
to regular meshes, as required for most optical calculations
To begin with it is necessary to define each node. The definitions
can either be placed at the top of the .smesh or .poly file, or
defined separately in a .node file, as has been done here.
# IPS.node
22 3 0 0 # no. of nodes, dimension (always 3), don’t want
a material no. for nodes
1 0 0 0
2 0 25 0
3 24 25 0
4 24 0 0
5 0 0 10
6 0 25 10
7 24 25 10
8 24 0 10
9 0 0 12
10 0 25 12
11 24 25 12
12 24 0 12
13 0 20 12
14 24 20 12
15 21 0 12
16 15 0 12
17 9 0 12
18 3 0 12
19 3 10 12
20 9 10 12
21 15 20 12
22 21 20 12
0
0 |
Each surface is defined in the file below. Multiple surfaces may
be defined on each face, but if the .smesh format it used, the created
volumes cannot contain holes. The first number on each line gives
the number of nodes that defines the surface, which are subsequently
listed. The final number is the material number of the surface.
The final region section of the file allows a material number to
be applied to volumes by defining a point at the centre of the volume,
and providing the material number.
# IPS.smesh
0 # A zero indicates the node list should read from file *.node
14 1 # number of surfaces, 1=material numbers given
4 1 2 3 4 2048 # FixLC-1
4 5 6 7 8 4096 # FixLC-2
8 9 13 21 16 17 20 19 18 1 # nothing
4 18 19 20 17 64 # Electrode-1
8 16 21 13 10 11 14 22 15 128 # Electrode-2
4 15 22 14 12 1 # nothing
4 1 2 6 5 3 # Periodic
4 4 3 7 8 3 # Periodic
4 1 5 8 4 2 # Neumann
4 2 6 7 3 2 # Neumann
5 5 6 10 13 9 3 # Periodic
5 8 7 11 14 12 3 # Periodic
8 5 9 18 17 16 15 12 8 2 # Neumann
4 6 10 11 7 2 # Neumann
0
# region
2 # Number of regions
# region number, {x,y,z} region centre, material number
1 5 5 5 4 # Domain-1
2 5 5 11 36 # Dielectric-1 |
